LM5101ASD/NOPB
Manufacturer:
Texas Instruments
Mfr.Part #:
LM5101ASD/NOPB
Datasheet:
Description:
Gate Drivers WSON-10 SMD/SMT HighSide, LowSide N-Channel MOSFET Independent
| Parameter | Value |
|---|---|
| Length | 4 mm |
| Width | 4 mm |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 10 |
| Height | 800 µm |
| Packaging | Reel |
| Thickness | 0.75 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Output Current | 3 A |
| Max Supply Voltage | 14 V |
| Min Supply Voltage | 9 V |
| Max Output Current | 3 A |
| Number of Channels | 2 |
| Turn-On Delay Time | 4 ns |
| Turn-Off Delay Time | 4 ns |
| Quiescent Current | 200 µA |
| Propagation Delay | 26 ns |
| Channel Type | Independent |
| Number of Outputs | 2 |
| Fall Time | 260 ns |
| Rise Time | 430 ns |
| Nominal Supply Current | 2 mA |
| Number of Drivers | 2 |
| Schedule B | 8542390000 |
| Logic Voltage | 2.3 V |
| High Side Voltage | 118 V |
| Gate Type | N-Channel MOSFET |
| Configuration | HighSide, LowSide |
